Description
The EasySolar 12/1600/70-16 is a comprehensive and efficient all-in-one solar power solution that combines an inverter, solar charge controller, and AC distribution in a single device. This system is designed to provide a seamless and hassle-free setup for off-grid or grid-connected applications.
It includes an integrated MPPT (Maximum Power Point Tracking) solar charge controller with a capacity of 100V and 50A, allowing you to connect solar panels and harness the maximum available solar energy for efficient charging of your batteries.
Features
- All-in-one solar power solution
- MPPT Solar Charge Controller
- An inverter/charger
- AC Distribution
- Easy to install with minimum wiring
All-in-one solar power solution:
The EasySolar combines an MPPT solar charge controller, an inverter/charger and AC distribution in one enclosure. The product is easy to install, with a minimum of wiring.
The solar charge controller: Blue Solar MPPT 100/50
Up to three strings of PV panels can be connected to three sets of MC4 (PV-ST01) PV connectors.
The inverter/charger: MultiPlus Compact 12/1600/70
The MPPT charge controller and the MultiPlus Compact inverter/charger share the DC battery cables (included). The batteries can be charged with solar power (BlueSolar MPPT) and/or with AC power (inverter/charger) from the utility grid or a genset.
AC distribution:
The AC distribution consists of a RCD (30 mA/16 A) and four AC outputs protected by two 10A and two 16A circuit breakers. One 16A output is controlled by the AC input: it will switch on only when AC is available.
PowerAssist:
Unique PowerAssist technology protects the utility or generator supply from being overloaded by adding extra inverter power when needed.
Unique solar application software:
Several software programs (Assistants) are available to configure the system for various grid interactive or stand-alone applications.
Applications:
Marine / RV's / Caravans / Off-Grid Systems / Tiny Houses / Cabins
More about Victron:
Victron Energy has a strong, unrivalled reputation for technical innovation, reliability, and build quality. Their products are widely considered to be a professional choice for independent electric power. Efficiently combining two or more distinct power sources is what they do best. Their products include sinewave inverters, sinewave inverters/chargers, battery chargers, DC/DC converters, transfer switches, battery monitors and more.
